It adopts imported high-brightness semiconductor chips and can be used in high-humidity environments. It has advantages such as high thermal conductivity, low light attenuation, pure color light, and no ghosting.
| Product Name | TXLED-09A | TXLED-09B |
| Max Power | 100W | 200W |
| LED Chip Quantity | 36pcs | 80pcs |
| Supply Voltage Range | 100-305VAC | |
| Temperature Range | -25℃/+55℃ | |
| Light Guiding System | PC Lens | |
| Light Source | LUXEON 5050/3030 | |
| Color Temperature | 3000-6500K | |
| Color Rendering Index | >70RA | |
| Lumen | 160 Imw | |
| LED Luminous Efficiency | 90% | |
| Lightning Protection | 10KV | |
| Service Life | >50000 Hours | |
| Housing Material | Die-cast Aluminum | |
| Sealing Material | Silicone Rubber | |
| Cover Material | Tempered Glass | |
| Housing Color | As Customer's Requirement | |
| Protection Class | IP66 | |
| Mounting Diameter Pption | φ60mm | |
| Suggested Mounting Height | 8-10m | 10-12m |
| Dimension(L"W"H) | 663*280*133mm | 813*351*137mm |
Without the need for preheating, it instantly reaches rated brightness upon power connection. This fully resolves the issues with traditional sodium lamps' slow start-up and challenging low-temperature lighting, making it appropriate for emergency lighting requirements.
Prevents dark spots on sidewalks by simultaneously covering the road surface and roadside green belts with an illuminance uniformity of at least 0.8.
Long-term stable operation in foggy and coastal regions is ensured by the potted and sealed LED chips and driver module, which resist salt spray and water buildup.
To get rid of dust and stains, clean the light body's surface every three months. Prevent dust buildup from interfering with light transmission and heat dissipation. Before wiping, turn off the electricity and use a gentle cloth moistened with neutral detergent.
Every year, check the sealing strip. To stop rainwater from seeping in and harming the LEDs, replace it as soon as it exhibits signs of aging or cracking.
Troubleshoot any loose wiring and routinely assess the driver power supply's operational condition. To avoid lightning damage, check the grounding of the light pole every six months.
During maintenance, there is no need to disassemble the LEDs, which lowers operating expenses.
